3-axle self-tracking
semi low loader on 205 tires

780 mm loading floor height

Looking for a 3-axle self-tracking semi on 205 tires?

This self-tracking trailer has an extremely low loading floor, allowing you to transport higher loads. Because the trailer can extend once, you can achieve a maximum length of 19.5 meters.

Ask us
your question!

Determine
your target price

General
specifications

  • 1x Extendable
  • Airsuspension selftracking
  • 205/65 R17.5 Tires
  • Fixed neck
  • Load capacity app. 30T

Technical
specifications

  • Kingpin load 18T
  • Bogie load 30T
  • Tare weight ca.10T
  • Platform height 780mm
  • Extension 6400mm
  • Total extended lenght 19480mm
Specification sheet
